Schluter Systems KK81152 32" x 60" Kerdi Shower Kit with Center Drain
A well-known kit from a leading brand
Create a maintenance-free shower without a mortar bed
32" x 60" with center drain hole
Can be cut down to size
Kerdi 32" x 60" Shower Kit KK81152 in PVC or ABS - Center Drain
The Schluter Kerdi-Shower-Kit is an all inclusive package containing each of the integrated family of components required to create a maintenance free, watertight, shower assembly without a mortar bed.
The Schluter-KERDI-SHOWER-ST/-SC tray and curb are made of expanded polystyrene (EPS) foam with a high compressive strength (57 psi). They provide a convenient, lightweight, and stable substrate for the Schluter-KERDI waterproofing membrane and tile. After the tile is installed and grouted, the assembly will support all the loads typical of tiled showers. This can include glass doors or glass block walls.
- This kit contains a 32" x 60" shower pan.
- Other sizes available:
- 72" x 72" (center drain)
- 48" x 48" (center drain)
- 32" x 60" (offset drain)
- You can also cut this kit down to size. Ideally, the tray should be cut by equal amounts on all four sides to ensure a consistent height of the first course of wall tile. However, slight differences can typically be made up with thin-set mortar when setting the floor tile. The shower base can also be extended past the perimeter of the shower tray using dry pack mortar.
The package includes:
| Name | Description | Quantity |
|---|---|---|
| KERDI-SHOWER-ST | Shower tray, 32" x 60", with center hole | 1 |
| KERDI-SHOWER-SC | Shower curb, 48" x 6" x 4-1/2" | 2 |
| KERDI 10M | Waterproofing membrane, 3'3" x 39' 4" | 1 |
| KERDI-BAND | Waterproofing strip, 5" x 33' | 1 |
| KERDI-DRAIN | Shower drain kit with:
| 1 |
| KERDI-KERECK-F | Preformed waterproofing corners | 4 inside and 2 outside |
This kit from bulk components DOES NOT include pipe or mixing valve seal - please order separately
Available Grates
| 4" Grate Options | ||||
|---|---|---|---|---|
| Stainless Steel | Anodized Aluminum | |||
Stainless steel (E) |
Oil-rubbed bronze (EOB) |
Brushed Nickel (ATGB) |
Brushed copper/bronze (AKGB) |
Brushed brass (AMGB) |
